slimBOX S411J1-MA

EMB-S411J1-MC-A01

Product Description

SKU: EMB-S411J1-MC-A01



Powerful, fast, multi-display support, and rugged build for embedded applications, slimBOX S411J1-MA has all it needs to bring speeding performance and powerful graphics to the table. Featuring the 9th Gen Intel Core i7 processor, it packs NVIDIA GeForce RTX 2070 graphics to deliver life-like graphics and video playback, and has a vast array of connectivity options including one USB 3.1 Type-C port, five USB 3.0 ports, Gigabit Ethernet, Killer 2.5G Ethernet, and Killer WIFI 6.



The dual HDMI 2.0, DisplayPort 1.4 and USB 3.1 Type-C with DisplayPort output delivers fluid viewing with 4K resolution at 60Hz for life-like motion, making slimBOX S411J1-MA the ideal solution for scientific visualization, digital art creation/production and CAD/CAM engineering. Support for software EDID emulation also makes the system perfect for digital signage and menu board applications.

Product Specifications

SKU: EMB-S411J1-MC-A01



Computing
System

Processor

9th Gen Intel Core i7-9750H
Hex-core 2.6Ghz/4.4Ghz, 12MB cache

Chipset

Intel HM370

System Memory

2 x DDR4-2666 SO-DIMM slot, Maximum 64GB

Graphics

Graphics Engine

NVIDIA GeForce RTX 2070
2304 Turing CUDA cores with 8GB 256-bit GDDR6

HD Video Capability

HDMI 2.0: 4096 x 2160 @60Hz

Storage

Mass Storage

1 x M.2 2242/2260/2280 key-M socket for NVMe SSD
1 x M.2 2242/2260/2280 key-M socket for Optane Memory
1 x 2.5" SATA-III HDD/SSD bay

Card Reader

SD/SDHC/SDXC

I/O Ports

Video Output

2 x HDMI 2.0,
1 x DisplayPort 1.4,
1 x USB Type-C (DP, USB 3.1 Gen1)

Audio

Microphone, Headphone

USB Port

5 x USB 3.0 Type-A
1 x USB 3.1 Type-C

LAN

1 x Gigabit LAN
1 x 2.5Gbps Killer LAN

Antenna

2 x External Antenna

WiFi

IEEE 802.11ax/ac/a/b/g/n MIMO 2X2 based on Killer AX1650

Watchdog Timer

Hardware WDT. Timeout value = 1 ~ 255. Unit: min, sec

Bluetooth

Bluetooth 5.0

Legacy I/O

1 x RS-232 serial port

Expansion

1 x M.2 2230 key-E socket for WIFI module

Mechanical

Case

Active cooling full metal enclosure
Dimension 227mm(W) x 202.5mm(D) x 62.5mm(H)

Power Supply

Universal AC Adapter O/P: DC 19.5V/330W
2 x AC power cords for US and EU regions

Operating Temperature

0°C ~ +40°C (main unit)

Case Mounting

L-shape mounting, VESA mounting holes,
Rubber feet, DIN rail holes

Supported Operating System

Windows 10 64-bit, Ubuntu 18.04 LTS

Longevity Support No
